LPG Generator 11kW GCE12000B 2 Wire Start Vanguard

Description

LPG Generator  GCE12000B  10kW (12kVA) 2 Wire Start

This generator runs on Propane (LPG) and can be connected to either standard propane bottles or a fixed propane tank. Equipped with AVR (Automatic Voltage Regulation), it ensures stable power output, making it suitable for sensitive electronic equipment and ideal for modern domestic use.

It features a Remote 2-Wire Start control panel with the Deep Sea DS3110, allowing for both manual and automatic start modes. The DSE3110 includes a backlit LCD display that provides clear readings of engine speed, operating hours, generator voltage, and frequency. It is designed to display warning alerts and shutdown statuses for added safety.

For protection, the unit will automatically shut down in the event of over/under frequency or high/low voltage and has an optional over-temperature shutdown feature.

Additionally, it can be supplied with a Battery Monitoring System, which automatically starts and stops the generator based on battery voltage—ideal for remote off-grid applications requiring automatic battery charging.

[ 2-wire start generator is a type of generator that can turn on and off automatically when needed, without requiring manual operation. It works by using two control wires connected to an external system, such as a battery monitoring system or an automatic transfer switch (ATS). When the system detects low battery voltage or a power outage, it sends a signal through the wires to start the generator. Once power is restored or the batteries are charged, the system sends another signal to stop the generator. This feature is commonly used in off-grid solar setups, backup power systems, and remote locations where automatic power management is needed.]

Important Considerations:

• Storage: Must be kept in dry conditions.
• Operation: Must be used in a dry, well-ventilated area. We offer an optional cooling and exhaust extraction kit for enhanced ventilation.

• Rated output: 9.1kW (11.4kVA @0.8pf)
• Max – 10kW (12kVA @0.8pf)
• Net Weight 144 kg
• Socket Outlets 1×63 orA + 1x32A or 2x16A
• LPG/Propane is non-toxic to ground water and soil
• Over temperature shutdown
• Wheel Kit C/W Fold Down Handles Yes
• Lifting Eye Yes
• Noise Level @ 7M 72dB(a)
• Custom-made
• Delivery 5-7 days
• For more specs check tab above

Call us with your questions on 01923 559 077 or Text Us with your question on – 07422 128 528

Generator Size

If you are not sure of the size of the generator, please see here for more details.
